ALL-IN-ONE
Technologies integrated into a single management suite

Multi-level connected machines.
Technological integration of laser cutting and tube bending

Increase your competitiveness with technological integration.


Combining all product lines is easy because it was designed from the outset and simplified by the use of a single BLMelements software suite so you can:

  • Eliminate semi-finished products to be handled and stored.
  • Eliminate intermediate processes and secondary machining operations, working in line or in parallel.
  • Eliminate errors resulting from the combined effect of several successive jobs.
  • Eliminate inefficiencies, plan and monitor your process from a single point of management.

Tube bending machine and Lasertube together to always get the part right from the start.

The laser-cut and bent tube right from the start. The smart Lasertubes and tube bending machines compensate for the deforming effects induced by bending offering you:

  • Easy programming even without experience. No rejects, no need for trial and error.
  • Precise and repeatable parts immediately.
  • Efficiency in the production of large or small batches.

Technological integration of laser cutting and tube bending

How the All-In-One works

The tube bending machine calculates the elongation of the material and communicates it to the Lasertube.
The Lasertube system corrects the position of the cutting geometries along the tube based on the information received and processes it.
The part is then passed to the tube bending machine which also compensates for the springback of the tube. The result is the laser-cut and bent tube to perfection.

The result is a laser-cut and bent tube right from the start.


All from one single management point. Artube.

Artube allows you to import curved tubes and get a single linear design for your Lasertube system.
The software estimates the deformations that the bending process will cause (springback and elongation), appropriately correcting the laser cutting path so your part is right from the start.



Find out more

Integrazione tecnologica fra taglio laser e curvatura del tubo

Always convenient integration! More on the multi-tube.

Eliminate the multiplying effect of costs on multi-tube products. Exploit the flexibility of integrated systems to make more parts of an assembly in a single nesting.

The length of each part is already correct because All-In-One calculates the elongations of the next bending step.

Technological integration of laser cutting and tube bending

Discover the machines you can integrate

Lasertube

LT5.10

The simplest way to enter the tube laser cutting world.

Tubes up to Ø 120 mm
2D cut
Fiber laser

Discover LT5.10

LT7

The fully automatic solution that guarantees maximum productivity and fast changeover.

Tubes from Ø 12 mm to Ø 152.4 mm
3D cutting mode
Fiber laser

Discover LT7

LT8.20

The solution with the widest working range in laser tube cutting.

Tubes up to Ø 240 mm
3D cutting mode
CO2 / fiber laser

Discover LT8.20

LT FIBER EVO
LT722D

The most productive solution for tubes of any section.

Tubes up to Ø 152.4 mm
2D cut
CO2 / fiber laser

Discover LT FIBER EVO

LC5

Combined laser system for tube and sheet metal cutting.

Tubes up to Ø 120 mm
Sheets up to 6000 mm x 2000 mm
Fiber Laser

Discover LC5

Tube bending machines

E-TURN

Ideal for complex parts without straight stretches between bends.

Tubes up to Ø 50.8 mm
Right-hand and left-hand in-process
All-electric technology.

Discover E-TURN

ELECT

Ideal for large diameter tubes without straight stretches between bends.

Tubes up to Ø 150 mm
Right-hand or left-hand convertible
All-electric technology.

Discover ELECT
Contact us without obligation for more information or to request a quote.
Ask our experts

Coil-fed bending with mandrel: productivity and quality without compromise.

With the production system fed from coil with mandrel, you can bend and shape the tube directly from coil achieving the required finish and the most stringent technological parameters (average radius, diameter, thickness, material).


Coil-fed manufacturing with mandrel

Coil-fed manufacturing with mandrel offers you:

Bending of tubes fed from coil with average radii smaller than 1D.
Production flexibility because you program your part and start production just in time.
Maximum productivity with parallel machining, in continuous cycles, even 24/7.
Eliminate semi-finished products to be handled and stored.
Ability to use the machines independently.


From coil...
Straight to the result

Feeding from coil

3-RUNNER
Cutting to size and end-forming

3-RUNNER
Bending with mandrel

SMART
Tube fed from coil, bent with mandrel and end-formed on both ends

From coil, bent with mandrel, and formed on both ends.

Add a tube end-forming machine to form the tube on both ends. With BLM GROUP tube end-forming machines, you can carry out a wide variety of machining operations: tapering, widening, closing, single or double flaring, end-cutting, cutting, rolling and threading.

Bending from coil with mandrel and end-forming in one handy software package

The simplicity of a single management point.

The software corrects and calculates the elongation that the tube will undergo during the bending process to cut the part to the correct length. No manual set-up or adjustments are needed.
With VGP3D, you manage all the machines involved in the process from a single control point.


Coil-fed processing with mandrel

3-RUNNER

For making cut and end-formed tubes quickly from coil, the starting point for 24/7 processes.

Tubes up to Ø 27 mm
Stainless steel, copper, iron, aluminium
All-electric technology

Discover 3-RUNNER

SMART

High-production tube bending machine for complex shapes with small to medium diameter tubes.

Tubes up to Ø 28 mm
Right-hand and left-hand in-process
All-electric technology

Discover SMART

Additional tube end-forming machines

E-SHAPE

Tube end-forming machine for tapering, widening, reducing, end-cutting, cutting.

Tubes up to Ø 50 mm
Up to 100 kN of thrust
All-electric technology

Discover E-SHAPE

E-FORM

Tube end-forming machine for tapering, widening, reducing, end-cutting, cutting, CNC rolling.

Tubes up to Ø 50 mm
Up to 100 kN of thrust
All-electric technology

Discover E-FORM
Contact us without obligation for more information or to request a quote.
Ask our experts

Tube bending and laser cutting integrated like never before.

Go into production faster and safer with your 3D laser cutting system.

With ArtCut, you can manage the scrap on bent tubes without having to draw it in CAD, importing it directly from VGP3D or creating it with a few simple clicks.

How to manage scrap on tubes bent with a 3D laser cutting system

Discover the machines with which to create your All-In-One process

3D laser cutting cells

LT-FREE

The most flexible and productive solution to enter the world of 3D laser cutting.

5-axis cutting head
Work area up to 3000 mm x 1000 mm
Fiber laser

Discover LT-FREE

LT360

The most cost-effective and versatile way to enter the 3D laser cutting world.

Cutting robot
Work area up to 1500 mm x 1000 mm
Fiber laser

Discover LT360

Tube bending machines

E-TURN

Ideal for complex parts without straight stretches between bends.

Tubes up to Ø 50.8 mm
Right-hand and left-hand in-process
All-electric technology

Discover E-TURN

ELECT

Ideal for large diameter tubes without straight stretches between bends.

Tubes up to Ø 150 mm
Right-hand or left-hand convertible
All-electric technology

Discover ELECT
Contact us without obligation for more information or to request a quote.
Ask our experts
 Workcell with tube bending machine, tube end-forming machine, and Lasertube

Workcells

Tube bending machines - Lasertubes - Tube end-forming machines - 3D laser cutting cells - Sawing machines.

All our systems can be equipped with automatic loading or unloading systems, robot unloading, and conveyors and can be integrated into workcells or within broader production chains.

With our integrated solutions you can:

  • Simplify logistics by eliminating intermediate steps and secondary machining operations
  • Reduce the cycle time and cost per part.
  • Control the entire system from a single management point.


Increase your production efficiency.

Protube provides reliable quotes and allows you to identify the best production strategy for both single parts and entire production batches.

It also allows you to manage logistics, planning, monitoring, and productivity analysis with the capability to integrate to your ERP.

All the systems communicate with each other and simulate the production processes to simplify the operator's work and resolve any detected problems.
